NDB1-125 Series Miniature Circuit Breaker
Updated:April 14,2021 11:54AM

Rated current from 50A 63A 80A 100A to 125A; Rated operational voltage (Ue) 230/240VAC (1P); 400/415VAC (2P 3P 4P); Rated limit short-circuit breaking capacity Icu: 10.0 kA.
2021 Quick Selection Guide >>

NDB1-125 Series Miniature Circuit Breaker
NDB1-125 Series Miniature Circuit Breaker
NDB1-125 Series Miniature Circuit Breaker

Description

Description of NDB1-125 Series

NDB1-125 series of circuit breakers used in the TT, TN-S ground system, provide the short circuit and overload protection, control and isolation functions. Applicable to the low-voltage terminal distribution in the industry, civil buildings, energy, communication, infrastructure and other fields.



Features

Features of NDB1-125 Series

  • When MCB normally open or trip because fault, the phase line and neutral line should keep disconnected status to avoid the electric hurt by electrified neutral line
  • Full Protection Functions with overload and short-circuit protection. When connect or do breaking operation, you should connect the neutral line at first, then do breaking operation
  • Connection is safety and reliable: use "Frame" connection structure
  • Easily mounting: TH35 standard mounting rail



Technology data

Technology data of NDB1-125 Series

Rated Insulation Voltage 500V
Rated Frequency 50/60Hz
Rated Impulse Withstand Voltage 6kV
Instantaneous Tripping Characteristic type C, type D



Datasheet of NDB1-125 Series

Nader-NDB1-125-Products-specification.pdf



FAQs

Questions & Answers for NDB1-125 Series

  • What is the function of miniature circuit breaker?
    A Miniature Circuit Breaker (MCB) is an automatically operated electrical switch used to protect low voltage electrical circuits from damage caused by excess current from an overload or short circuit.
  • What is miniature circuit breaker how it works?
    A miniature circuit breaker (MCB) automatically switches off the electrical circuit during an abnormal condition of the network means in overload condition as well as faulty condition. Nowadays we use an MCB in a low voltage electrical network instead of a fuse. Handling an MCB is electrically safer than a fuse.
  • What is mean by miniature circuit breaker?
    miniature circuit breaker: a small trip switch operated by an overload and used to protect an electric circuit, esp a domestic circuit as an alternative to a fuse.
  • How does a house breaker work?
    Inside each circuit breaker is a spring hooked over a small piece of solder (a melt-able fusible alloy). Each breaker is connected to an electrical wire that runs through your house. The electricity that flows through your house runs through the solder.
  • What is the advantage of miniature circuit breaker?
    MCB (Miniature Circuit Breaker) is a circuit breaker with optimum protection facilities of overcurrent and short circuit only. Its basic function is to detect the fault condition and interrupt the current flow. it avoids overheating in case of excess current & provides fire protection.
  • What is the difference between MCCB and MCB?
    MCB is miniature circuit breaker which is used to break small currents. Like in domestic LT circuits. The ratings usually end up to 100 A. MCCB is a Module case circuit breaker which has a rugged construction as it can break larger currents usually from (100-1000A).
